Collaboration diagram for ufbx_texture:
Data Fields | ||
| union { | ||
| ufbx_element element | ||
| struct { | ||
| ufbx_string name | ||
| ufbx_props props | ||
| uint32_t element_id | ||
| uint32_t typed_id | ||
| } | ||
| }; | ||
| ufbx_texture_type | type | |
| ufbx_string | filename | |
| ufbx_string | absolute_filename | |
| ufbx_string | relative_filename | |
| ufbx_blob | raw_filename | |
| ufbx_blob | raw_absolute_filename | |
| ufbx_blob | raw_relative_filename | |
| ufbx_blob | content | |
| ufbx_nullable ufbx_video * | video | |
| uint32_t | file_index | |
| bool | has_file | |
| ufbx_texture_layer_list | layers | |
| ufbx_nullable ufbx_shader_texture * | shader | |
| ufbx_texture_list | file_textures | |
| ufbx_string | uv_set | |
| ufbx_wrap_mode | wrap_u | |
| ufbx_wrap_mode | wrap_v | |
| bool | has_uv_transform | |
| ufbx_transform | uv_transform | |
| ufbx_matrix | texture_to_uv | |
| ufbx_matrix | uv_to_texture | |
The documentation for this struct was generated from the following file:
- include/mgdl/ufbx/ufbx.h
